Circuit Works keeps a set of sheets about small machines and their parts. Each one starts from a single photograph and stays honest about what that photograph can and cannot show.

Method

  1. Look first. Note only what is visible: parts, joins, marks, damage.
  2. Number the notes so each one can be found again on the photograph.
  3. Keep facts short, and write “not stated” rather than guess a size or value.
  4. Add a dated revision whenever a better look changes a note.

What a sheet holds

What a sheet holds
PhotographOne object, framed on the grid
CalloutsNumbered observations
Bill of materialsParts that can be seen and counted
RevisionsDated notes, oldest first

The sheets are deliberately modest. A photograph can show how parts sit together, where something is damaged and what can be counted. It cannot show sizes, values, what a machine does well or whether a fault was fixed, so none of that appears here unless it was measured.

The photographs are real CC0 images; see the photo credits.
