CMP-01
Five memory modules in a row
Five laptop memory modules laid parallel on a pale surface: a quick record of chips, edge contacts and notches.
- Material
- Components
- Drawn
- Status
- Observation study
- Drawn by
- Circuit Works
The modules are lined up on a plain white surface and photographed from a low angle, so the nearest two are sharp and the back three soften.
Capacity and speed are not stated anywhere on this sheet: the photograph does not settle them.
Callouts
- Five laptop-size modules lie parallel on a pale surface.
- Each shows four black chips on its visible side.
- Gold edge contacts carry a notch set off-centre.
- Only the nearest two are in sharp focus.
Revisions
Rev A · · First look
Counted the modules and the chips on each.
Rev B · · Focus note
Added that only the nearest two modules are sharp, so later notes stay with those two.
